1064nm 200MHz Polarization-Maintaining Fiber Acousto-Optic Modulator (AOM)

1064nm 200MHz Polarization-Maintaining Fiber Acousto-Optic Modulator (AOM)

parameter
material :TeO2
wavelength:1064nm
Average optical power handling :  3W
Peak (pulsed) optical power:  3kW
Ultrasonic sound velocity : 4200m/s
Insertion loss  :3dB
Polarization Extinction Ratio：18dB
Extinction ratio : 50dB
Return loss: 40dB
Rising edge time ：10ns
frequency :200MHz
Frequency shifting : +/-200MHz
Frequency stability: 200+/-0.1%MHz
RF power :2.5W
Voltage VSWR :1.5:1
Input impedance:  50Ω
Device interface SMA
Fiber type ：PM980
Fiber length： 1m
Fiber optic interface： FC/APC
Operating temperature ：-20~60℃
Storage temperature ：-30~70℃
