815nm 10mW-70mW infrared fiber-coupled laser pro-single-mode round dot FC

815nm 10mW-70mW infrared fiber-coupled laser pro-single-mode round dot FC

[Specification]

Wavelength: 816 ± 5nm
Exit pupil power: 10mW-50mW (coupled power)
Divergence angle: 0.6mrad
Optical system: optically coated glass
Lenses, high-quality aspherical plastic lenses
Fiber core diameter: single-mode 4.5um
Cladding size: 125um
Fiber outer diameter: 0.9mm
Injection Numerical Aperture: 0.12
Spot description: The smaller spot diameter at 50cm is Φ0.3mm, and the spot size can be adjusted according to the use distance
Fiber length: 1 meter (do not fold the fiber optic cable, it cannot be repaired)
Fiber Material: Quartz
Operating voltage: DC 3V
Laser class: II., III.a, III.b
Operating temperature: -10°C~50°C;
Storage temperature: -40°C~80°C
Dimensions: Φ16mm×60mm
