980nm 25mW 40mW FP SM coaxial laser diode

980nm 25mW 40mW FP SM coaxial laser diode

parameter

Model: LSFLD980-25
Wavelength：980nm
Output power：25mW.
Reverse voltage:2V
Operating Current:140mA
Operating Voltage:2V
Soldering temperature(time):260℃
Operating temperature:-10～+50℃
Storage temperature:-15～+85℃

Features:
MQW F-P LD
Single mode
Built-in monitor PD
Metal can type hermetic
Low threshold/operate current
Hig

Applications:
Optical Sensing
Industrial automatic control
Science analysis and experiment
Test and Measurement Equipment

Model: LSFLD980M-40
Wavelength：980nm
Output power：40mW.
Reverse voltage:2V
Operating Current:450mA
Operating Voltage:1.8V
Soldering temperature(time):260℃
Operating temperature:-10～+60℃
Storage temperature:-40～+85℃

Features:
MQW F-P LD. multiple mode
Metal can type hermetic
Low threshold/operate current
High reliable

Applications:
Optical Sensing
Medical instrument
Industrial automatic control
Science analysis and experiment
Test and Measurement Equipment
Laser range finder

LSFLD980-25 980nm 25mW FP SM coaxial laser diode

LSFLD980M-40 980nm 40mW FP SM coaxial laser diode
