980nm 50mW laser tube infrared ultra-small laser module dot diameter 6mm 6.5mm 8mm

980nm 50mW laser tube infrared ultra-small laser module dot diameter 6mm 6.5mm 8mm

[Specification]

Wavelength:   980nm

Optical Output:50mW

Reverse Voltage:2V

Operating Temperature:- 10 ～ 40℃

Storage Temperature:- 20 ～ 85℃

Electrical and Optical Characteristics(Tc=25℃)

Threshold Current:10mA

Operating Current:80mA

Operating Voltage:1.8Volt

Slope Efficiency :0.8mW/mA

Monitor Current :0.9mA

Beam Divergence:6deg

(FWHM)  :   32deg.

Central wavelength :980 (±10)nm

and θ⊥ are defined as the angle within which the intensity is 50% of the peak value
